Standard Ral Color PE / PVDF 0.5-1.0mm prepainted Aluminum coil used for produce wall panels

Changzhou Dingang Metal Material Co.,Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Standard Ral Color PE / PVDF 0.5-1.0mm prepainted Aluminum coil used for produce wall panels

Brand Name : Dingang

Model Number : Dingang - PPAL

Certification : SGS,ITS,BV

Place of Origin : China

MOQ : 1000 Kgs / 1 Metric Ton

Price : Negotiable

Payment Terms : T/T,L/C

Supply Ability : 5000 Tons / Per Month

Delivery Time : Within 35 Days After Order Confirmed And Down Paymetn Received

Packaging Details : Seaworthy Packing With Wooden Pallet

Sample : available

Trademark : Dingang

Delivery Port : Shanghai

Origin : China

Surface treatment : Coated

Standard : ASTM AISI JIS DIN GB

Contact Now

Description


This standard RAL color PE/PVDF prepainted aluminum coil, available in 0.5-1.0mm thickness, is designed for wall panel production. Combining aesthetic appeal with functional durability, it offers a wide range of RAL-compliant colors to match architectural designs. The PE coating provides excellent corrosion resistance and UV stability, while PVDF options enhance weatherproofing for harsh environments.

With smooth surfaces and consistent gloss levels (10-60°), the coil ensures easy forming into various wall panel shapes, including curved or embossed profiles. It meets ISO 12944 corrosion protection standards and RoHS environmental requirements. Ideal for interior/exterior wall cladding, commercial facades, and decorative panels, this product balances long-term performance with design flexibility.


Material Composition


Base Material: Aluminum alloy (e.g., 3003, 5005) in H14/H24 temper

Coating Type:

PE Coating: Polyethylene top coat + primer layer (for general environments)

PVDF Coating: Polyvinylidene fluoride top coat + primer layer (for extreme weather resistance)

Total Coating Thickness:

PE: 25-35μm (total)

PVDF: 35-45μm (total)

Performance Features

Formability: Smooth surface for easy bending, folding, and embossing into wall panel profiles (e.g., flat, corrugated, or curved).

Weather Resistance:

PE: Suitable for moderate climates with UV protection.

PVDF: Exceptional durability in coastal/high-temperature regions (15+ years outdoor service).

Corrosion Protection: Primer layer enhances adhesion and resistance to moisture, chemicals, and pollutants.

Color Consistency: Standard RAL colors ensure uniform appearance across batches.


Application Scope


Interior/Exterior Wall Cladding: Commercial buildings, residential complexes, and public infrastructure.

Decorative Panels: Ceilings, partitions, and facade accents.


Standard Ral Color PE / PVDF 0.5-1.0mm prepainted Aluminum coil used for produce wall panels
